DSG-01 solenoid direcctional valve电磁换向阀
发布时间:2019-12-19 17:32
浏览次数:
Features
  1. These are Solenoid Operated Directional Valves of high pressure, high flow and low pressure drop, the features of which can be materialized by employing a powerful wet type solenoid and the rational flow channel design.
2. In conformity with the ISO standard, the installation is absolutely interchangeable.
3.  Connected to the common terminal, the 50HZ and 60HZ can overcome the disturbance of varied frequencies.
4.  Both plug-in solenoid easy to changeable coil.
5.  The light beaming direction of movement is distinctive.
DSG-01 series operated directional valve 电磁换向阀
特性
  1. 湿式电磁设计、做动平稳无冲击、噪音值低。
  2. ISO标准、安装尺寸具有绝对互换性。
  3. 50Hz、60Hz共用端子结构,解决不同周波之扰。
  4. 插入型电磁设计,分解组立非常容易。
  5. 灯光指示做动方向,明确清楚。

Specifications性能参数
型号
Model number
最大流量
Max.flow
L/min
最高使用压力(MPa)
Max working pressure
最高允许背压 (MPa)
Max back pressure
最高切换频率(次/分)
Max change over frequency
质量Mass(kg)
DSG-01-3C※-※-50
DSG-01-2D2-※-50
DSG-01-2B※-※-50
63 31.5仅滑阀机能60型25
Spool type 60 only 25
16 300 2.2
1.6
1.6
