Features
1.  These are Solenoid Operated Directional Valves of high pressure, high flow and low pressure drop, the features of which can be materialized by employing a powerful wet type solenoid and the rational flow channel design.
2． In conformity with the ISO standard, the installation is absolutely interchangeable.
3.  Connected to the common terminal, the 50HZ and 60HZ can overcome the disturbance of varied frequencies.
4.  Both plug-in solenoid easy to changeable coil.
5.  The light beaming direction of movement is distinctive.

特性

1. 湿式电磁设计、做动平稳无冲击、噪音值低。
2. ISO标准、安装尺寸具有绝对互换性。
3. 50Hz、60Hz共用端子结构，解决不同周波之扰。
4. 插入型电磁设计，分解组立非常容易。
5. 灯光指示做动方向，明确清楚。

Specifications性能参数

型号 Model number	最大流量 Max.flow L/min	最高使用压力(MPa) Max working pressure	最高允许背压 (MPa) Max back pressure	最高切换频率(次/分) Max change over frequency
DSG-03-3C※-※-50 DSG-03-2D2-※-50 DSG-03-2B※-※-50	120	31.5仅滑阀机能60型25 Spool type 60 only 25	16	240
