4WE 10 series operated directional valve 电磁换向阀
Features

1. These are Solenoid Operated Directional Valves of high pressure, high flow and low pressure drop, the features of which can be materialized by employing a powerful wet type solenoid and the rational flow channel design.

2． In conformity with the ISO standard, the installation is absolutely interchangeable.
3.  Connected to the common terminal, the 50HZ and 60HZ can overcome the disturbance of varied frequencies.
4.  Both plug-in solenoid easy to changeable coil.
5.  The light beaming direction of movement is distinctive.

特性

1. 湿式电磁设计、做动平稳无冲击、噪音值低。

2. ISO标准、安装尺寸具有绝对互换性。
3. 50Hz、60Hz共用端子结构，解决不同周波之扰。
4. 插入型电磁设计，分解组立非常容易。
5. 灯光指示做动方向，明确清楚。


Specifications性能参数

型号Model	最大流量Max.flow （L/min）	最高使用压力 Max. pressure （ Mpa）		最高切换频率 Max. change over frequency （次/小时）cpm
		A、B、P	T	直流DC	交流AC
4WE10E※ 4WE10G※ 4WE10H※ 4WE10J※ 4WE10L※ 4WE10D※ 4WE10C※ 4WE10D/OF※ ………	120	31.5	21	15000	7200
